COLORED PVC STRIPS
COLORED PVC STRIPS
COLORED PVC STRIPS,Flexible PVC STRIP,PVC Film,PVC Sheet
DERFFLEX, An industry leader in the PVC Strip Curtain & PVC film segments!
I.Benefits of COLORED PVC STRIPS
Clear PVC Films deliver the superior benefits of the heavy duty PVC material with the added advantage of a completely clear view. This premium quality waterproof fabric is resistant to UV rays, chemicals, grease, and mildew. The clear tarps perform exceptionally well in extreme weather from very hot to bone chilling cold. They are more than sturdy against wind, rain, or snow. These heavy duty tarps are most often used as porch and patio curtains, equipment tarps, and material covers where the viewing and transmission of light are important.
a.Waterproof
b.Abrasion Resistant
c.Oil Resistant
d.Grease & Mildew Resistant
e.High UV Resistance
f.Double-polished
g.Great For Patio's And Outdoor Enclosures
II. The features:
Can produce colored and colorless super transparent films with high grade transpancy and good glossing.
The products meet the international standards of the low toxicity,design meet customer's requirements
c. The range of the hardness from 26PHR-60PHR(according to samples)
III.Technical Data of PVC Film
|
PROPERTY |
Standard |
Unit |
Value |
|
Shore A hardness |
EN ISO 868 |
Sh A |
80 |
|
Tearing resistance |
DIN 53515 |
N/mm |
50 |
|
Tensile strength at break |
ASTM D 638 |
N/mm² |
16 |
|
Elongation at break |
% |
340 | |
|
Residual elong. (after break) |
% |
68 | |
|
Thermal conductivity |
ASTM C 177 |
W/m.K |
0,16 |
|
Cold bend brittle temperature |
ISO 8570 |
°C |
-35 |
|
Usage temperature range |
EN 1876 |
°C |
-15/+50 |
|
Vicat softening temperature |
EN ISO 306 |
°C |
50 |
|
Specific heat capacity |
ISO 11357 |
kJ/kg.K |
1,6 |
|
Sound reduction |
DIN 52210 |
dB |
>35 |
|
Reaction to fire |
CFM |
|
|
|
Light transmittance |
ASTM D 1003 |
% |
85 |
|
UV/IR filter |
AWS |
Filter |
- |
|
UV resistance |
ISO4892 |
- |
Yes |
|
Charge buildup |
IEC 61087 |
Sparks |
Yes |
|
Surface resistivity |
IEC 60093 |
.1012 Ω/ |
40 |
|
Water absorption |
EN ISO 62 |
% |
-0,2 |
|
Density |
ASTM D 792 |
g/cm3 |
1,22 |
IV. Aplicacion of Flexible PVC STRIP
Derflex is one of the leading PVC Sheet manufacturers in China with a history of 20 years. For more information please contact me:
